| Model | WIS-SG50 |
| Ethernet | 5*RJ45 10/100/1000Mbps |
| Switching Capacity | 10Gbps |
| Packet Forwarding Rate | 7.4 Mpps |
| Packet Buffer | 1M |
| MAC Address Table | 1K |
| Jumbo Frame | 2Kbytes |
| Transfer Mode | Store and forward |
| MTBF | 100000 hour |
| Standards and Protocols | IEEE 802.3i/802.3u/ 802.3ab/802.3x, IEEE 802.1p |
| Industry Standard | EMI: FCC Part 15 CISPR (EN55032) class A EMS: EN61000-4-2 (ESD) EN61000-4-4 (EFT) EN61000-4-5(Surge) |
| Network Medium |
10Base-T : Cat3,4,5 or above UTP(≤100m) 100Base-TX : Cat5 or above UTP(≤100m) 1000Base-TX : Cat5 or aboveUTP(≤100m) |
| Environment |
Operating Temperature: 0–40 °C (32–104 °F) Storage Temperature: -40–70 °C (-40–158 °F) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing |
| LED Indicators | PWR（Power indicator）、LOOP（Loop alarm）、Link（Network Link） |
| DIP Switch |
VLAN：Port Isolation, 1-4 ports are isolated each other, all communicate with uplink port 5; Default：Default mode, all ports communicate with each other; Extend：Monitor Mode, 1-4 ports support 100M speed reduction negotiation, support 250 meters in 10Mbps/s mode, port 5 as uplink port； |
| Dimensions | 84*47*25mm |
| Weight | 0.18kg |
| Max Power Consumption | 2.3 W (220 V/ 50 Hz) |
| External Power Supply |
External Power Adapter (Output: 5 V DC / 0.6A) |
| Security Certificae | CE、FCC、RoHS |
