In The Box
Downloads

Product Overview

The WCAP-AX-Lite Access Point is one of the wireless products fully developed by WIS Networks.
The device supports 802.3af/at PoE In power supply. With concurrent 2.4GHz and 5GHz the AP
supports dual-band dual-stream MIMO technology,providing 574Mbps at 2.4G, and 2402Mbps at 5G.

Integrated Fat/Fit AP + AC Architecture

WisCloud Controller is refined designed to suit all Wisnetworks enterprise class AP equipments.
A single controller can centrally supervise and manage the WiFi networks and multiple,
distributed APs could be taken care and work in a more effective way.

Easy-to-use Interface

No special training is required to operate the controller system. The main parameters of one/multi-WU\N networks is
available on the dashboard. Simple design would also help to easily realize the real-time status monitoring and customized

One minute network configuration

Using the intelligent centrally management between Ac and AP can quickly synchronize wireless configuration into each AP
tocomplete a unified construction of the wireless network.

Unlimited AP Numbers

Unlimited AP numbers controlled by WisCloud controller would provide best experience for customers to plan and
expand the WU\N networks.

Enterprise Level Radio Chipset

The high speed 1.2GHz Qualcomm CPU and 512MB DDR makes WisCloud access points much powerful to
provide a stable connectivity and multifunctional wireless networks.

Supports Fat AP & Fit AP Mode

All wireless network solution is completed by integrated fit ap and controller.
While fat AP is quite perfect for users who owns a few APs.working with standalone.
Fit AP is more suitable for enterprise / ISP level wireless network and massive deployment.
WisCloud AP supports both alternatives.

Support for Standard 802.3af/at

WisCloud Access Point is able to be supplied power 802.3af PoE technology and
make it more flexible to deploy the device in indoor ceiling environment.

Various APs Optional

meet different requirements from customers, we provide corresponding AP with different feature
parameters including frequency, speed, tx power and installation method etc.

Physical Characteristics
Model	WCAP-AX-Lite
Type	Indoor
CPU	IPQ5018
Size of RAM	256MB
FLASH	16MB
802.11b/g/n	√
802.11b/g/n/ac/ax	√
Wireless 2.4 GHz Max data rate	574Mbps
Wireless 5GHz Max data rate	2402Mbps
Tx power	23dBm
Ethernet	1 Gbps
Max power consumption	18W
Secondary Ethernet Port	×
POE IN	802.3af/at
DC IN	×
Ceiling Mount	√
Pole Mount	×
Size
Weight	0.5kg
Tested ambient temperature	-40°C to 70°C
Certification	CE, FCC, ROHS
