Hardware |
|
|
Model |
ODU20-CAT4(EU) |
|
CPU |
MTK7621 CPU@880MHz,Dual-core |
|
LTE standard |
3GPP Release 9 |
|
Modem |
Quectel EC200A Mini PCle |
|
Max DL/UL Rate |
LTE TDD: 150Mbps/50Mbps LTE FDD: 130Mbps/30Mbps HSPA+/HSDPA:21Mbps/5.76Mbps WCDMA:384kbps/384kbps EDGE:236.8kbps/236.8kbps GPRS:85.6kbps/85.6kbps |
|
Modem Frequency Band |
LTE TDD: B1/B3/B5/B7/B8/B20/B28 LTE FDD: B38/B40/B41 WCDMA : B1/B5/B8 GSM: B3/B8 |
|
Wi-Fi |
N/A |
|
Antenna Frequency |
698-3800MHz |
|
Antenna Gain |
Max 20dBi |
|
MIMO |
2*2 |
|
Led Indicator |
1*PWR , 1*LTE, 1xETH, 3*Signal strength |
|
Ports |
1*SIM card slot, 1*Gigabit Ethernet ports |
|
Power Supply |
Gigabit PoE, Typical value 24V 1A |
|
Ingress Protection: |
IP65 |
|
Software Functions |
Pv4, Static Routing, Routing Forwarding APN Dynamic NAT SNMP DHCP Server,DHCP Rela |
|
Physical Properties |
|
|
Dish material |
aluminum |
|
Antenna Size |
60cm |
|
Weight |
2.5g |
|
Operating Temperature |
0~+40℃ |
|
Storage Temperature |
-20~+70℃ |
|
Humidity |
95% (No-condensing) |
