Hardware |
|
|
Model |
ODU20-CAT6(PH) |
|
CPU |
MTK7621 CPU@880MHz,Dual-core |
|
LTE standard |
3GPP Release 11,Cat 6 |
|
Modem |
SLM828 |
|
Max DL/UL Rate |
LTE (Cat.6):Max 300Mbps(DL)/50Mbps(UL) DC-HSPA+:Max 42Mbps(DL)/5.76Mbps(UL) WCDMA: Max 384kbps(DL)/384kbps(UL) |
|
Modem Frequency Band |
LTE-FDD：B1/B3/B5/B7/B8/B20/B28/B32 LTE-TDD：B38/B40/B41 WCDMA：B1/B3/B5/B8 |
|
Wi-Fi |
N/A |
|
Antenna Frequency |
698-3800MHz |
|
Antenna Gain |
Max 20dBi |
|
MIMO |
2*2 |
|
Led Indicator |
1*PWR , 1*LTE, 1xETH, 3*Signal strength |
|
Ports |
1*SIM card slot, 1*Gigabit Ethernet ports |
|
Power Supply |
Gigabit PoE, Typical value 24V 1A |
|
Ingress Protection: |
IP65 |
|
Software Functions |
Pv4, Static Routing, Routing Forwarding APN Dynamic NAT SNMP DHCP Server DHCP Rela |
|
Physical Properties |
|
|
Dish material |
aluminum |
|
Antenna Size |
60cm |
|
Weight |
2.5g |
|
Operating Temperature |
0~+40℃ |
|
Storage Temperature |
-20~+70℃ |
|
Humidity |
95% (No-condensing) |
