Product Overview

Outdoor 4G LTE CPE devices offer similar features to the Indoor CPE but are weather-proof All-Outdoor Units

with high gain directional antennas, integrated IP bridge/router and Power-over-Ethernet technology, to

provide long range coverage and connectivity to the LTE base stations. The outdoor CPE are used to provide

xDSL equivalent connections for last-mile and Internet Service Providers.

Hardware
●  Integrated  Cat 4 LTE modem
●  Wi-Fi Wireless Speed up to 300Mbps
●  24v PoE powered
●  Internal antennas

Features and Benefifits
- 4G transform to Wi-Fi
- Flexible power supply 24V POE/DC for selection
- IP65 Outdoor Protection Level
- Support multiple frequency range
- Internal antennas
- Up to 8kV ESD protection

Wi-Fi Specifications
Standard	IEEE 802.11b/g/n
Channel Bandwidth	20 MHz, 40 MHz,
Frequency	2.4 GHz
MIMO	2x2
Peak Rate	802.11b: 11 Mbps 802.11g: 54 Mbps 802.11n: 300 Mbps
Sensitivity	65 dBm @ 54 Mbps, typical for 802.11g 76 dBm @ 11 Mbps, typical for 802.11b
Max Output Power	14±3 dBm
Antenna Gain	5 dBi
LTE Specifications
Standard	Cat 4
Band	Integrated Firewall WPA/WPA2;WPA-PSK/WPA2-PSK (AES/TKIP) Encryption; 64/128-bit WEP;
LED	Power：On/Off LAN:On/Off/Flashing WLAN:On/Off/Flashing RSSI Signal:1,2,3
Power Supply	12VDC, 1A
Dimensions	CE, RoHS
Package content	H300-LTE Radio Quick Setup Guide Power Adapter with Passive PoE Mounting bracket & kits
