AC1200-POE

2.4/5GHz Dual-band PoE Router

CPU
MT7621
Wireless Standards
IEEE 802.11a/b/g/n/ac
Frequency
2.4 GHz and 5 GHz dual-band
Channel Width
20/40/80 MHz
Networking interface
1*10/100/1000 Mbps WAN with 24V PoE output 2*1000 Mbps LAN port
Antenna Gain
5dBi
Dimensions
183.5*120*173mm
Weight
500g
  • AC1200-POE
  • AC1200-POE
  • AC1200-POE
  • AC1200-POE
  • AC1200-POE
  • AC1200-POE
  • Features

  • Specification

  • In The Box

  • Downloads

Product Overview

The WIS-AC1200-POE is a 2.4/5GHz 1200Mbps 4x4 MIMO PoE Router based on 802.11 ab/g/n/ac technology,
its 4*5dBi High gain antennas design wall penetration Wi-Fi. Its WAN port support 24V Passive PoE Output.
The router provides PoE power to outdoor devices through the Ethernet connection,
thus the outdoor device needn't separate power connection or adaptor.

Features
- Gigabit WAN with 24V PoE output
- 2*Gigabit LAN port
- IEEE 802.11a/b/g/n/ac 1200Mbps Wi-Fi
- dual-band 2.4 GHz and 5 GHz
- 4*5dBi High gain antennas
- Switch: Off/Router/POE


Typical Applications


Model

AC1200-POE

AC1200

Processor

MT7621

Standard

IEEE 802.11b/g/n/ac

Memory

128MB

 Flash

16MB

Frequency

2.4 GHz and 5 GHz dual-band

Channel Bandwidth

20 MHz, 40 or 20 MHz, 40 MHz, 80 MHz

WAN Port

1*10/100/1000 auto-sensing,  auto-MDX

PoE Output

24V DC PoE / 1A

LAN Port

2*10/100/1000 auto-sensing,  auto-MDX

Power Supply

Input: Universal range 100V-240V AC

Switch

Off/Router/POE

Reset Button

Press for 10 seconds to restore the

router to its factory settings

LEDs

Power/SYS/POE

Peak Rate

802.11b: 11 Mbps

802.11g: 54 Mbps

802.11n: 300 Mbps

802.11ac: 866 Mbps

Sensitivity

-64 dBm @ 65 Mbps, typical for 802.11n/ac

-65 dBm @ 54 Mbps, typical for 802.11g

-76 dBm @ 11 Mbps, typical for 802.11b

Transmit Power

20±3 dBm

Antenna

Internal 5dBi omni, 4T4R

Active Users

64

Environment

Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Certification

CE, RoHS
